噴膠機(含視覺)
您當前的位置是:首頁>>產品中心>>噴膠機(含視覺)
< >
JL -P15060 數控噴膠機
材質:
規格:
承重:
顏色:0.00
聯系電話:0769-85877871
  • 產品簡介
  • 產品案例

20200403031503698.jpgJL—P15060  數控噴膠機

主要用途:適用于手袋,銀包,箱包,鞋類,禮品盒等行業材料的噴膠。

工作范圍:800mm x 500mm

適用膠水: 白膠,水性膠,亞么尼亞膠

主要優點:

1:提高效率,節省人手:噴膠運行平穩,速度快,可節省2-4人,有效提高生產效率,降低人工成本。

2、節省膠水,降低成本:運行穩定的數控噴膠系統,進口氣動噴槍控制精細,噴膠均勻,膠水寬度3-50mm,比傳統噴膠節省膠水40%-60%。

3、操作簡單,方便;手動,腳踏,和自動控制系統。用戶可直接在觸屏上進行任意圖形的設定,操作簡單方便(手動輸入或示教的方式輸入均可)。系統可儲存圖形多達999個(規則或者不規則)。

4、環保節能:設備具備抽風系統,可將噴膠時產生的膠水味和霧氣進行過濾處理,設備待機時,噴膠裝置全封閉,防止膠水揮發

主要參數:

型號

Model

JL-P15060

額定電壓

Rated voltage

AC220V

額定功率

Rated power

0.75KW

噴膠范圍

Working area

1500mm*600mm

抽風方式

Take out wind way

風筒式軸流抽風機

外形尺寸

Dimensions

1500x900x1400mm

X軸驅動電機

The X axis drive motor

85系列混合式二相45NW步進電機

Y軸驅動電機

The Y axis drive motor

85系列混合式二相85NW步進電機

下槍方式

Spray gun down way

手動調節

最大速度

Maximum speed

50mm/s



JL—P15060 Numerical control spray glue machine

MAIN APPLICATION:It `s suitable to spray glue large area for handbag ,wallet ,luggage ,footwear,gift box etc.

WORKING AREA:Effective working area 800mm*500mm

SUITABLE GLUE: White glue ,water-based glue ,Chloroprene adhesive

PRODUCT FATURE:

1、To improve efficiency ,save labor costs ,spray glue speed fast ,can save around2-4 workers ,effectively to improve the production efficiency,reduce labor costs.

2、Save the glue ,to reduce the cost :It has automatic glue control system,spray glue more correct,and it also hans adjustable spray glue gun head,the spray width is 3-50mm,it saves glue 40%-60% than finishing by hand。

3、High operation efficiency :the machine run stable ,it can spray glue uniform and thin,faster than the traditional brush glue ,the glue easy to bi dry,bonding stronger,workers paste fast.operation efficiency is high.

4、Easy to operation:the machine is designed with manually operation ,foot pedal and automatic control system ,besides ,you can set the spray glue graph on the touch screen ,you can choice manual set on the touch screen or use USB to transport the graph and stored graphics up to 999(regular or irregular).

Main parameter:


型號

Model

JL-P15060

額定電壓

Rated voltage

AC220V

額定功率

Rated power

0.75KW

噴膠范圍

Working area

1500mm*600mm

抽風方式

Take out wind way

Wind rube axial flow fan

外形尺寸

Dimensions

1500*900*
1400mm

X軸驅動電機

The X axis drive motor

85 Series,45 NW hubrid two -phase stepper motor

Y軸驅動電機

The Y axis drive motor

85 Series,85 NW hubrid two -phase stepper motor

下槍方式

Spray gun down way

Manual adjust

最大速度

Maximum speed

50mm/s
